Screw slide rail

2024-07-25 11:54:17

When designing or selecting a linear displacement actuated device, there are many factors to consider: operational load, speed, accuracy, environmental and power requirements are all very important.Whether it is an advancing ball screw, a precision fixed ball screw or a lead screw, careful consideration should be given to the selection of grease.Selecting the right grease can minimize friction, reduce torque, increase screw efficiency and prolong service life.This requires the grease to have excellent high and low temperature performance, strong anti-oxidation and rust resistance, good lubricity, excellent adhesion and oil film forming ability etc.

Grease has the following functions:

(1)Reduces friction between moving parts, preventing coking and reducing wear.

(2)Forms an oil film on the rolling surface to reduce stress on the surface and prolong rolling fatigue life.

(3)Apply oil film to metal surface to prevent rust.

Types of lubricants

Linear motion system mainly uses grease or sliding surface oil as its lubricant.The requirements that lubricants need to meet generally include the following:(1) High oil film strength (2) Low friction (3) High wear resistance (4) High thermal stability (5) Corrosion resistance. (6) High rust resistance (7) Low dust and moisture content (8) Even after repeated stirring, the consistency of the grease will not change significantly.

VNOVO slide grease has a wider working temperature, is non-toxic, odorless and non-irritating, and fully meets the requirements of environmental protection;Good compatibility with plastic and metal;And has strong oxidation resistance, rust resistance, water resistance, corrosion resistance, long-lasting lubrication;Good load bearing performance, can effectively reduce losses;Contains fiber additives for extremely strong adhesion to reduce grease loss;Strong oil film forming ability, can effectively reduce wear and noise;And there are a variety of viscosities to choose from, can adapt to the needs of different situations.

Application Details

Application	Design Requirements	Recommended Products	Application
Dustproof Grease	Less dust, long life, wear-resistant	AFE-CA	Synthetic oil polyurea formulation for clean room.
Anti-fretting wear	Vacuum, dust-free environment, load-resistant, fretting-resistant	AFF	Synthetic oil lithium soap, placement machine screw guide, ball screw screw.
Low temperature grease	Low temperature resistance, long life, anti fretting wear	AFC	Suitable for guideway bearings, low starting torque
General purpose screw grease	Long life, wear resistance, oxidation resistance	AFB-LF	Extreme pressure lithium base grease formulated with mineral oil for bearings, guides, screws.
High temperature screw grease	High temperature, high speed ball screw	LR3	Medium load,used for high speed screw.
High speed screw grease	Long life, wear resistance, high temperature resistance, oxidation resistance	PS2	Fully synthetic oil polyurea formulation with special solid additives.
